Item |
Standard specifications |
|||
Frequency Range F0 |
10to 11.999MHz |
12 to 19.999MHz |
20 to 23.999MHz |
24 to 6400MHz |
Mode of Vibration |
Fundamental |
|||
Load Capacitance CL |
6to 20pF |
|||
Frequency Tolerance △F/ F0 |
±10ppm, ±15ppm,±30ppm(At 25℃) |
|||
Equivalent Series Resistance ESR |
150 Ωmax. |
100Ω max. |
70Ω max. |
50Ω max. |
Temperature Stability TC |
±10ppm,±15ppm,±30ppm(Refer to 25℃) |
|||
Operating Temperature Range TOPR |
-20~+70℃ -40~+85℃ Option |
|||
Storage Temperature Range TSTG |
-55~+125℃ |
|||
Shunt Capacitance C0 |
3pF max. |
|||
Insulator Resistance IR |
500MΩ min. (At 100V) |
|||
Drive Level DL |
100µW (200µW max.) |
|||
Aging Fa |
±2ppm max. (At 25℃, First year) |
|||
Packing Unit |
3000pcs/reel |
|||
