晶体谐振器 | |||||
封装尺寸 | 频率范围(Mhz) | 频率偏差 (ppm) | 工作温度 (°C) | 负载电容(pF) | 粤博型号 |
11.05×4.65×3.5 | 3.5 to 90 | ±5ppm ~ ±20 ppm | -40 to +85 | 5 to 30 | HC-49S |
12.5×4.65×3.7 | 3.5 to 90 | ±5ppm ~ ±20 ppm | -40 to +85 | 5 to 30 | HC-49SSMD |
7.0×4.1×2.0 | 3.5 to 90 | ±5ppm ~ ±20 ppm | -40 to +85 | 5 to 30 | M7-49S |
2.0×1.6×0.65 | 16 to 80 | ±5ppm ~ ±20 ppm | -40 to +85 | 5 to 30 | 2016贴片晶振 |
2.5×2.0×0.5 | 12 to 80 | ±5ppm ~ ±20 ppm | -40 to +85 | 5 to 30 | 2520贴片晶振 |
3.2×2.5×0.75 | 12 to 150 | ±5ppm ~ ±20 ppm | -40 to +85 | 5 to 30 | 3225贴片晶振 |
5.0×3.2×1.3 | 8 to 125 | ±5ppm ~ ±20 ppm | -40 to +85 | 5 to 30 | 5032贴片晶振 |
TCXO | |||||
封装尺寸 | 频率范围(Mhz) | 频率偏差 (ppm) | 工作温度 (°C) | 电源电压 (VCC) | 粤博型号 |
2.0×1.6×0.8 | 16 to 80 | ±0.5ppm ~ ±20 ppm | -40+85 | 1.8 to 3.3 | 晶体振荡器2016 |
2.5×2.0×0.9 | 12 to 80 | ±0.5ppm ~ ±20 ppm | -40+85 | 1.8 to 3.3 | 晶体振荡器2520 |
3.2×2.5×1.0 | 12 to 150 | ±0.5ppm ~ ±20 ppm | -40+85 | 1.8 to 3.3 | 晶体谐振器3225 |
5.0×3.2×1.3 | 8 to 125 | ±0.5ppm ~ ±20 ppm | -40+85 | 1.8 to 3.3 | 晶体谐振器5032 |
32.768kHZ晶振 | |||||
封装尺寸 | 频率范围(kHZ) | 频率偏差 (ppm) | 工作温度 (°C) | 负载电容(pF) | 粤博型号 |
1.6×1.0×0.45 | 32.768 | ±5ppm ~ ±20 ppm | -40 to +85 | 6 to 12.5 | SMD32.768kHZ |
2.0×1.2×0.55 | 32.768 | ±5ppm ~ ±20 ppm | -40 to +85 | 6 to 12.5 | SMD32.768kHZ |
3.2×1.5×0.8 | 32.768 | ±5ppm ~ ±20 ppm | -40 to +85 | 6 to 12.5 | SMD32.768kHZ |
